Fuwa platen （connection platen）

Fuwa platen (connection platen)

1. Function

• Structural Support:

The Fuwa 90 small direct-connected support is designed to provide robust structural reinforcement for trailer or truck axle systems, ensuring stability and load-bearing capacity.

• Vibration Damping:

Its compact design and high-strength materials help absorb and dampen vibrations, reducing wear on connected components and extending service life.

• Modular Integration:

Designed for seamless integration with Fuwa's axle and suspension systems, simplifying installation and maintenance.

2. Specifications

(Note: Specific dimensions may vary by model; the following are general descriptions.)

• Size:

Typically rated for 90 mm (3.54 in) axle diameters or compatible with 90 mm-width support structures.

• Mounting:

Direct-connected to axle or chassis via bolted or welded flanges, ensuring secure attachment.

• Load Capacity:

Rated for dynamic and static loads up to several tons (e.g., 5–10 tons, depending on the application).

3. Material

• High-Strength Carbon Steel:

The main body is often made of forged or rolled carbon steel (e.g., Q235, Q345) with a tensile strength of ≥400 MPa.

• Corrosion-Resistant Coatings:

Zinc plating, hot-dip galvanizing, or powder coating to resist rust and environmental damage.

• Wear-Resistant Surfaces:

Key contact areas may be hardened or treated with anti-friction coatings to reduce wear.

4. Key Parameters

• Weight:

Typically weighs 5–15 kg (11–33 lbs), depending on size and design.

• Dimensions:

• Length: 100–300 mm (3.94–11.81 in)

• Width: 90 mm (3.54 in)

• Height: 50–100 mm (1.97–3.94 in)

• Tolerance:

Dimensional tolerances of ±0.5 mm (±0.02 in) to ensure compatibility with axle systems.

• Temperature Range:

Operates effectively in temperatures ranging from -40°C to +120°C (-40°F to +248°F).

• Cycle Life:

Rated for ≥1,000,000 loading cycles without failure, ensuring durability in heavy-duty applications.

5. Additional Features

• Self-Aligning Design:

Some models include self-aligning features to simplify installation and reduce misalignment risks.

• Adjustable Mounting:

Slotted or adjustable mounting holes allow for fine-tuning of position during installation.

• Compliance with Standards:
